Bilstein standard

Bilstein Sports B6 FRONT shock absorber Insert.
34-000403 cartridge type shock will fit all models of 944 but Porsche changed the design on the front in late '1986 to make them non-rebuild-able, so this insert type will not fit late 1986 on wards.



Fits:
Porsche 944 2.5L / 2.5L S / 2.5L Turbo
Porsche 924 2.0L / 2.0L Carrera GT / 2.0L Turbo / 2.5L S 11/1975-08/1989

Fits cars:
- with Suspension Strut Manufacturer Boge, for bolted struts only,

Fitting Position: Front Axle
Shock Absorber Type: Gas Pressure
Shock Absorber Design: Suspension Strut Insert
Shock Absorber Mounting Type: Top pin
Suspension Strut Manufacturer: Boge
Strut outside diameter: 50 mm

Note: If your car has sealed shocks it will require the top of the shock to be cut off in order to make it fit.

The shock absorber for those drivers who prefer a sports suspension but are not particularly interested in lowering the body. Also available in special design complete with reservoir for off-road vehicles.
No risk, more fun
For some people it's important to show what they have, for others it's sufficient to know that they have it. The theme of the discussion here is the sports suspension. The BILSTEIN B6 Sports shock absorber is the ideal solution for drivers revelling in the understatement . The wolf in sheep's clothing snarls, when necessary, but otherwise goes reliably about its work in daily traffic with no lowering of the body whatsoever.

Optimum road holding, enhanced tracking stabilisation and excellent damping force: the BILSTEIN B6 Sports is not only first choice as far as sports tuning is concerned but also in the sphere of safety.

Please Note:
Price is for each damper you will need to buy 2

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

34-000403

The product you are viewing cross references to these numbers

Shock Absorber Front (FICHTEL + SACHS Replacement shock absorber.)

Fits:
Porsche 944/944s 1987-89 Cars Without Sport Suspension



Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

94434303

The product you are viewing cross references to these numbers

Threaded sleeves (PAIR) for Porsche 944 S2 968 damper leg for Bilstein B6 shock absorbers.

Fits:
Porsche 944 S2 / 968

Threaded sleeves for the conversion of two standard shock absorber legs of the Porsche models 944 S2 and 968. They allow the use of Bilstein B6 shock absorbers.

Procedure:

1. chisel open the grouting of the old shock absorber parts and pull-out shock cartridges.

2. shorten the tubes by 44.5mm

3. remove the zinc layer from the threaded sleeves in the welding area

4. carefully hammer threaded sleeves into the tubes and weld well all around (Before welding, check that the gap between the tube and threaded sleeve fits. It must be possible to tighten the damper cartridge with the nut with 5 full turns).

5. sand the weld smooth, paint and assemble the shock absorber

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

7305

The product you are viewing cross references to these numbers
