T-SPOILER Advanced spoiler control unit. Porsche 964 / 993  ❭  96461821200

T-SPOILER Advanced spoiler control unit.



Fits:
Porsche 964 1989-94
Porsche 993 1994-98

The BERGVILL F/X T-SPOILER Advanced Spoiler Control Unit is a direct replacement for the original spoiler control unit used in all Porsche 964 and 993 models. By default, it operates in the same way as the original module, but with several enhancements. The unit offers the possibility to change the spoiler rise and lower trigger speeds, as well as a very convenient One-Click feature for easy manual operation. It has also a fault code LED that will tell you what is wrong if the spoiler warning light is triggered. Porsche part # 96461821200, 964 618 212 00 or similar

Download installation manual here

Basic features, similar to the original unit

• Manual control by using the spoiler switch
• At start, the warning light extinguish at 5 km/h
• Spoiler rise at 80 km/h (50 MPH)
• Spoiler lowering at 5 km/h (3 MPH)
• Timer control in rise and lower movement
• No manual or One-Click lowering of spoiler if above rise speed
• T-SPOILER enhanced features

• Microprocessor control
• Solid-state MOSFET motor driver
• Spoiler motor current monitor and automatic shutoff with fault warning
• User programmable One-Click operation, no need to hold switch at manual operation
• User programmable rise and lower trigger speeds
• Safety raising of spoiler at 150 km/h (93 MPH)
• Internal LED fault readout monitor
• Dimensions: 57x27x16mm, weight 19g (Porsche unit 105x49x28mm, 80g)

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

96461821200

The product you are viewing cross references to these numbers
