Drive by wire inlet conversion kit with inlet manifold runners Plastic version. Porsche 911  ❭  96411090130

Fits:
Porsche 911 - 1974 - 1989

Please Note:
The aluminium or plastic intake plenum (inlet manifold) is not included in the kit.

Product Overview:

Inject power and precision into your vintage aircooled engine

Conversion kit for the 911 G-model to become a DBW (Drive by wire) intake based on the 964 induction and using the 74mm original Bosch throttle body (Sometimes referred to as 76mm). This is intended to breathe a bit more life into a classic G-model.

The kit includes

• Throttle body runner for 74mm throttle body
• Original Bosch electronic throttle body
• Original Bosch MAP-T-sensor
• Resonance tube
• Vacuum solenoid
• Connectors and hose
• Vacuum check valve
• Intake runners for the Porsche 911 G-model engine

Intake runners are made out of billet aluminium, 3D milled in a 5-axis machine. The port diameter indicated in the options is the diameter of the port in the cylinder head. Please note that these are the 2-bolt designs.

To create a bit of intimacy between you and your engine we have included a bit of DIY work for you to convert the Porsche 964 intake into this version.  This kit does not come with 964 intake manifolds so you will need so source a pair  separately.

The intake also exists in two versions (billet aluminium or PA12 plastic) - this version is what we at Islandworks use with all other intakes, being a modified PA12 material from an industrial manufacturing process. Both options have the same performance and the same durability with the difference being the look and feel of a 5-axis machined piece as the very first thing you lay your eyes on when you open the engine decklid.
For both options the lower resonance tube is made from our usual modified PA12 in black.

The following parts will be reused from the 964 intake:

• Rubber boots and clamps
• Vacuum reservoir
• The aluminium or plastic plenums
• Resonance flap, actuator and shaft

Please Note:
The aluminium or plastic intake plenum is not included in the kit and neither are any of the items specifically listed as excluded above.
