Porsche > Diagrams > 997 (911) MK2 2009-2012 > 997 MKII Carrera C4 3.6L 2009>> > Transmission >

Manual gearbox / heat exchanger / oil pipe / Water pipe - G9100, G9130 - 991.1 2012-16

Manual gearbox / heat exchanger / oil pipe / Water pipe - G9100, G9130 - 991.1 2012-16 - PORSCHE

Click the image numbers to view product info

Diagram 302-015 Porsche 997 MKII Carrera C4 3.6L 2009>> Transmission SKU: 7PP906283C, change-over valve,SKU: 9A7906283, change-over valve f 99-fs111 979>> f >> 99-fs111 978 also use:,SKU: 99161294400, wire set for change-over valve f >> 99-fs111 978 SKU: 9P1317233, disc valve SKU: 90091800540, pipe 5,0 x 1,0 vacuum line running meter SKU: 9P1317830, bracket disc valve SKU: 9P1317188, hose SKU: 9P1317186A, hose (complete) SKU: 99951265609, hose clamp 25 x 12 SKU: 99951265609, hose clamp 25 x 12 SKU: 99951265609, hose clamp 25 x 12 SKU: 99951265609, hose clamp 25 x 12 SKU: PAF008124, torx screw bm 6 x 12 SKU: 99951307540, cable ties 1,5 - 50,0 SKU: 99923904440, hose 3,5 x 2,0 x 130 SKU: 99923904040, connecting piece 3,5 x 2,0 x 28 SKU: 99923904040, connecting piece 3,5 x 2,0 x 28 SKU: N91068201, hexagon socket flat head bolt m 4 x 10 SKU: 9A712109303, cable holder 22,0 / 22,0 SKU: 90091811040, pipe 5,0 x 1,0 vacuum line running meter SKU: 9P1129487, molded hose SKU: 99950786640, line holder 4,3 / 4,3 SKU: 9G130701900, heat exchanger also use: pos.18, pos.19, 9g130724100,SKU: 9P1301131, seal SKU: 9P1399265C, flat round head bolt m 6 x 55 SKU: 9P1399265B, flat round head bolt m 6 x 20 302-015
