Other diagrams
801-00
body in white prime coated sealed with underbody protection 964 1989-94
801-03
body front section 964 1989-94
801-05
frame front 964 1989-94
801-10
frame centre 964 1989-94
801-15
frame rear 964 1989-94
801-17
rear-axle cross-tube 964 1989-94
801-20
interior panelling front 964 1989-94
801-25
interior panelling rear 964 COUPE 1989-94
801-26
interior panelling rear 964 TARGA/CABRIO SPEEDSTER 1989-94
801-30
exterior panelling front 964 1989-94
801-31
exterior panelling centre 964 COUPE 1989-94
801-33
exterior panelling centre 964 TARGA/CABRIO SPEEDSTER 1989-94
801-35
exterior panelling rear 964 COUPE 1989-94
801-40
exterior panelling rear 964 TARGA/CABRIO SPEEDSTER 1989-94
801-43
cover body front section 964 1989-94
801-45
cover underbody 964 1989-94
801-50
cover wheel housing 964 1989-94
802-00
bumper front 964 1989-94
802-05
bumper rear 964 1989-94
802-07
heat protection for bumper rear 964 1989-94
803-00
lid front 964 1989-94
803-05
lid rear 964 1989-94
803-10
rear spoiler 964 CARRERA 2/4, CARRERA RS, TURBO-LOOK 1989-94
803-15
rear spoiler driving mechanism 964 CARRERA 2/4, CARRERA RS, TURBO-LOOK 1989-94
803-20
rear spoiler 964 TURBO 1989-94
804-00
door in white 964 1989-94
804-02
seal doors 964 COUPE TARGA CABRIO 1989-94
804-03
seal doors 964 SPEEDSTER 1989-94
804-04
door latch 964 1989-94
804-06
central locking system 964 1989-94
804-10
power windows electric 964 CARRERA 2/4, RS, M002, TURBO, TURBO-LOOK 1989-94
804-11
power windows electric 964 SPEEDSTER 1989-94
804-12
power windows manually 964 CARRERA RS 1989-94
804-15
door glass frame 964 COUPE 1989-94
804-20
door glass frame 964 TARGA, CABRIO, SPEEDSTER 1989-94
805-00
window glazing 964 COUPE 1989-94
805-05
window glazing 964 TARGA/CABRIO 1989-94
805-10
window glazing 964 SPEEDSTER 1989-94
807-00
interior equipment FRONT luggage compartment 964 1989-94
807-01
linings footwell detachable carpets 964 1989-94
807-02
interior equipment adhesive carpets 964 1989-94
807-05
interior equipment rear 964 COUPE/TARGA 1989-94
807-06
interior equipment roof roll bar 964 COUPE TARGA UPTO 1993
807-07
interior equipment rear 964 CABRIO, SPEEDSTER 1989-94
807-13
interior equipment doors 964 SPEEDSTER 1989-94
807-15
body sound proofing 1 for 964 1989-94
809-00
dashboard knee protection strip for cars without airbag 964 1989-94
809-01
dashboard trim airbag for LEFT HAND DRIVE Cars 964 1991 ONWARDS
809-02
knee protection strip airbag for cars with glove compartment cover locking device left for LEFT-HAND DRIVE cars 964 1991 ONWARDS
809-03
knee protection strip airbag for cars with glove compartment cover locking device centre for LEFT _HAND DRIVE cars 964 1989-94
809-05
glove compartment for cars without airbag sun visors 964 1989-94
809-10
interior mirror, door mirror 964 CARRERA 2/4 UPTO 1991
809-12
interior mirror, door mirror 964 TURBO, TURBO-LOOK,CARRERA 2/4, CARRERA RS M002 1992 ONWARDS
809-13
interior mirror, door mirror 964 CARRERA RS, SPEEDSTER 1989-94
809-15
centre console 964 1989-94
810-00
insignias stone guard film 964 1989-94
810-05
sill cover 964 1989-94
811-00
sunroof 964 1989-94
811-05
soft top 964 TARGA 1989-94
811-06
windscreen frame accessories 964 TARGA/CABRIO 1989-94
811-12
main folding top bow roof frame single parts 964 CABRIO 1989-94
811-13
convertible top clamp single parts 964 CABRIO 1989-94
811-15
convertible top covering seal single parts 964 CABRIO 1989-94
811-16
convertible top cover 964 CABRIO 1989-94
811-20
convertible top convertible top frame 964 CABRIO 1989-94
811-21
convertible top driving mechanism 964 CABRIO 1989-94
811-22
convertible top catch 964 CABRIO 1989-94
811-30
folding top complete main folding top bow single parts 964 SPEEDSTER 1989-94
811-31
convertible top covering, convertible top frame, single parts 964 SPEEDSTER 1989-94
811-32
folding top, seal, roof frame 964 SPEEDSTER 1989-94
811-35
rear covering 964 SPEEDSTER 1989-94
811-36
rear covering, control shaft, single parts 964 SPEEDSTER 1989-94
811-40
tonneau cover 964 CABRIO 1989-94
812-00
seat belt front 964 TURBO / CARRERA 2/4 TURBO-LOOK 1989-94
812-01
seat belt seat belt front 964 CARRERA RS, SPEEDSTER1989-94
813-00
ventilation heating system 1 for 964 1989-94
813-01
ventilation heating system 2 for 964 1989-94
813-05
heater air conditioner single parts 964 1989-94
813-10
water drain tube, mount, wiring harness heater, air conditioner 964 1989-94
813-15
compressor 964 1989-94
813-20
compressor, mounting, driving mechanism 964 CARRERA 2/4/RS M64.01/02/03 1989-94
813-22
compressor, mounting, driving mechanism 964 TURBO /M64.5 M30.69 1991-94
813-25
refrigerant circuit front 964 1989-94
813-30
refrigerant circuit rear 964 1989-94
813-40
control switch driver 964 1989-94
813-45
condenser blower front 964 1989-94
interior equipment doors 964 CARRERA RS 1989-94 - PORSCHE
Click the image numbers to view product info
807-12
