OE Match

This is a brand new set of 4 Grant 90mm rings.

Fits:Porsche 914 1.7L
Ring size: 2.0 x 2.0 x 5.0.
Number of CYL's: 4

This is a new set of 6 JE Pistons.



JE Forgings are made from 2618 Aluminum, They have a 0 offset with extra material under the top for the valve pockets.

Fits: Porsche 911S 2.2L / 2.4L

Engine size: 2.2/2.4L
Stroke: 66/70.4mm
Pistons: JE 2618 Forged

Kit includes: 6 Pistons, A set of Piston Rings, and 6 wrist pins and clips.

OPTIONS:
1. 84mm - High compression
The Compression ratios are 10.1:1 with the 66mm crank and 10.6:1 with the 70.4mm.
2. 86mm - Low compression
The Compression ratios are 9.2:1 with the 66mm crank and 9.5:1 with the 70.4mm.
3. 86mm - High compression
The Compression ratios are 10.5:1 with the 66mm crank and 11.2:1 with the 70.4mm.

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

0089118

The product you are viewing cross references to these numbers

This is a new set of 6 cast pistons. Graphite Coated Hypereutectic pistons with valve pockets, and the 22mm Pin.



Fits: Porsche 911S 2.2L / 2.4L

Engine size: 2.2/2.4L
Stroke: 66/70.4mm
Pistons: Hypereutectic

Kit includes: 6 Pistons, A set of Piston Rings, and 6 wrist pins and clips.

OPTIONS:
1. 84mm - Low compression
The Compression ratios are 8.5:1 with the 66mm crank and 9.1:1 with the 70.4mm.
2. 84mm - High compression
The Compression ratios are 9.1:1 with the 66mm crank and 9.7:1 with the 70.4mm.
3. 86mm - High compression
The Compression ratios are 9.5:1 with the 66mm crank and 10.7:1 with the 70.4mm.

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

0089118

The product you are viewing cross references to these numbers

This is a new set 86mm Porsche 356/912 JE pistons.



Fits: Porsche 356C, SC, 1963-66 & Porsche 912; 1965 and Up with the 3 piece case.

JE Forged pistons with 30° Angle. JE Forgings are made from 2618 Aluminum, They have a 0 offset with extra material under the top for the valve pocket

Engine size: 1600cc
Stroke: 74mm
Pistons: JE 2618 Forged
Dome Height: .155
Compression: 9.5:1
Piston Angle: 30°

Kit includes: 4 Pistons, A set of Piston Rings, and 4 wrist pins and clips.

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

0081186JEP

The product you are viewing cross references to these numbers

This is a new set 86mm Porsche 356/912 JE Pistons.



Fits: Porsche 356A and 356B, Super 90, 1955-63 with the 3 piece Case.

JE Forged Pistons with 22° Angle. JE Forgings are made from 2618 Aluminum, They have a 0 offset with extra material under the top for the valve pocket.

Engine size: 1600cc
Stroke: 74mm
Pistons: JE 2618 Forged
Dome Height: .155
Compression: 9.5:1
Piston Angle: 22°

Kit includes: 4 Pistons, A set of Piston Rings, and 4 wrist pins and clips.

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

0081186JEAP

The product you are viewing cross references to these numbers

This is a new set of Big Bore 86mm Porsche 356/912 pistons.



Fits: Porsche 356C / SC 1963-66 & Porsche 912 1965 and Up with the 3 piece Case.

Graphite Coated Hypereutectic pistons with the 30° Angle, valve pockets, and the 22mm Pin.

Engine size: 1600cc
Stroke: 74mm
Pistons: Hypereutectic
Dome CC: 17
Compression: 9.2:1
Piston Angle: 30°

Kit includes: 4 Pistons, A set of Piston Rings, and 4 wrist pins and clips.

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

0081186SP

The product you are viewing cross references to these numbers

This is a new set of Big Bore 86mm Porsche 356 pistons.



Fits: Porsche 356 A and B, Super 90, 1955-63 with the 3 piece Case.

Graphite Coated Hypereutectic pistons with the 22° Angle, valve pockets, and the 22mm Pin.

Engine size: 1600cc
Stroke: 74mm
Pistons: Hypereutectic
Dome CC: 17
Compression: 9.2:1
Piston Angle: 22°

Kit includes: 4 Pistons, A set of Piston Rings, and 4 wrist pins and clips.

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

0081186EP

The product you are viewing cross references to these numbers

This is a new set Porsche 356/912 JE High Compression pistons.



Fits: Porsche 356 C / SC 1963-66 & Porsche 912 1965 and Up with the 3 piece case.

JE Forgings are made from 2618 Aluminum, They have a 0 offset with extra material under the top for the valve pocket and the 30° Angle. This is a High Compression Piston kit 11.5:1 more commonly used in race-cars .

Engine size: 1600cc
Stroke: 74mm
Pistons: JE 2618 Forged
Dome Height: .295
Compression: 11.5:1
Piston Angle: 30°

Kit includes: 4 Pistons, A set Piston Rings, and 4 wrist pins and clips.

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

008118

The product you are viewing cross references to these numbers

This is a new set of 80mm Porsche 356 pistons. It fits Pre "A" Porsche 1948-55 with the early 2 piece Case. Pistons are Graphite Coated Hypereutectic with valve pockets, and the 22mm Pin.



Fits: Porsche 356 Pre A 1500cc

It is also commonly used as a big bore supplement for the early 36 Horse VW Engine, but requires a lot of machine work.

Engine size: 1500cc
Stroke: 74mm
Pistons: Hypereutectic

Kit includes: 4 Pistons, A set of Piston Rings, and 4 wrist pins and clips.

Related reference numbers
Related, superseded, cross reference or alternative numbers for comparison.

0081180P

The product you are viewing cross references to these numbers

This is a new set of Type 4 flat top JE Pistons.



JE Forgings are made from 2618 Aluminium, They have a 0 offset with extra material under the top for the valve pockets. This set comes with a 34.6mm Compression Height and the 24mm Pin. The slightly smaller compression height allows you to easily build small stroked engines 71 to 78mm with the Standard length rods that have the 24mm pins giving you the option to Build 2.3L and bigger Engines.

Engine Type : Porsche 914, VW Type 4, Bus or Sandrail.

Stroke: 71 to 78mm
Pistons: Forged JE
Compression Height: 34.60mm
Pin: 24mm

Set includes: 4 pistons, 4 pins, 4 clips and a set of rings

This is a new set of Type 4 flat top JE Pistons.



JE Forgings are made from 2618 Aluminium, They have a 0 offset with extra material under the top for the valve pockets. This set comes with a 34.6mm Compression Height and the 24mm Pin. The slightly smaller compression height allows you to easily build small stroked engines 71 to 78mm with the Standard length rods that have the 24mm pins giving you the option to Build 2.3L and bigger Engines.

Engine Type : Porsche 914, VW Type 4, Bus or Sandrail.

Stroke: 71 to 78mm
Pistons: Forged JE
Compression Height: 34.60mm
Pin: 24mm

Set includes: 4 pistons, 4 pins, 4 clips and a set of rings

This is a new set of Type 4 2.0 liter flat top JE Pistons.



JE Forgings are made from 2618 Aluminum, They have a 0 offset with extra material under the top for the valve pockets. This set comes with a 30.08mm Compression Height with a 22mm Pin. The smaller compression height allows you to build large stroked engines 78 to 86mm using longer rods that have the 22mm pins.

Engine Type : Porsche 914, VW Type 4, Bus or Sandrail.
Engine size: 2000cc

Stroke: 78 to 86mm
Pistons: Forged JE
Compression Height: 30.08mm
Pin: 22mm

Set includes: 4 pistons, 4 cylinders, 4 pins and a set of rings

This is a new set of Type 4 2.0 liter 96mm flat top JE Pistons.



Engine Type : Porsche 914, VW Type 4, Bus or Sandrail.
Engine size: 2000cc

JE Forgings are made from 2618 Aluminum, They have a 0 offset with extra material under the top for the valve pockets. This set comes with a 34.6mm Compression Height and the 24mm Pin. The slightly smaller compression height allows you to easily build small stroked engines 71 to 78mm with the Standard length rods that have the 24mm pins.

Stroke: 71 to 78mm
Pistons: Forged JE
Compression Height: 34.60mm
Pin: 24mm

Set includes: 4 cylinders, 4 pins and a set of rings

Dished Piston Set, 94x71mm.



Fits: Porsche 914, Type 4
Engine size: 2000cc

Stroke: For 71mm stroke crankshafts
Pistons: Hypereutectic aluminium alloy
Compression Height: 35.5mm
Dish cc: 10cc

Set includes: 4 pistons, 4 cylinders, 4 pins and a set of rings

Dished Piston Set, 93x66mm.



Fits: Porsche 914, Type 4
Engine size: 1800cc

Stroke: For 66mm stroke crankshafts
Pistons: Hypereutectic aluminium alloy
Compression Height: 42mm
Dish cc: 10cc

Set includes: 4 pistons, 4 cylinders, 4 pins and a set of rings

Flat top Piston Set.

Engine Type : Porsche 914, VW Type 4, Bus or Sandrail.

Stroke: 71 to 78mm
Pistons: Hypereutectic aluminium alloy
Compression Height: 35.50mm
Pin: 24mm

Set includes: 4 pistons, 4 pins and a set of rings.
